Most commercial pump failures start as small, ignored faults: a dirty inlet strainer, low oil, a long bypass run, or a dry start. A useful checklist is short, repeatable and taken from the model manual. It is not a licence to open a pressurised system, and it is not a single interval copied from another brand.
What should you check on a pressure washer pump before each shift?
Isolate the machine first. Check guards, hoses, the gun, the nozzle, couplings and the oil or fluid levels the manual assigns to the operator. Confirm a clean, steady water supply and a clear inlet filter. Do not run the pump dry. Follow the oil, bypass and shutdown steps in the model manual.

Tag out any damaged pressure part or safety control before the machine is used. High-pressure water is a jetting hazard, as WorkSafe Victoria sets out in its alert on high-pressure water jetting. This page is a pump-care checklist. Pump design is covered in the pump types guide, and hour-based planning is covered in the maintenance schedule.
Protect the pump through the water supply
The pump can only send on the water it is given. A kinked inlet hose, a starved tap, or grit in the strainer is a common path to cavitation, seal wear and pulsing. Confirm that the supply can provide a clean, continuous flow at the inlet the manual names, then straighten the hose and clean the user-serviceable strainer.
The Freshway listing for the Kranzle 133003 inlet filter describes a 3/4 inch female inlet and male outlet, a 40 L/min maximum flow and a serviceable sieve. That accessory is a protection device, not a cure for a tap that cannot keep up. The inlet flow guide explains how to check supply against the machine’s required litres per minute.
Prime or purge as the manual instructs before you ask the pump for pressure. Official Kranzle operating manuals for the K1152TST and the KHD7/122TS say you should never let the high-pressure pump run dry for more than 60 seconds. Treat that as a hard limit for those machines, not a target.
Oil, milky oil and why intervals are not generic
Check the oil level only in the way the manual shows, usually a sight glass or dipstick, with the machine isolated and on level ground. Do not start a pump that the manual says must have oil visible. If the oil is grey, white or milky, stop work: that appearance often means water has entered the crankcase.
Official intervals differ by brand, which is why a copied “change it every 50 hours” rule is unsafe.
| Source, checked for this draft | What it says about pump oil |
|---|---|
| Official Kranzle operating manuals for the K1152TST, K2160TST and HD7/122TS QC, hosted by Powerblast | First oil change after approximately 50 operating hours, then every year or after 250 operating hours. If the oil turns grey or white, change it. |
| Official HW1310 operating manual, hosted by Powerblast | Check the level by sight glass or dipstick. If the oil has a milky appearance, call the technical service centre immediately. Change the oil after the first 50 hours, then every 500 hours or once a year. |
| Official HW1408 operating manual, hosted by Powerblast | Lists an oil change in the high-pressure pump every 500 hours as a service-centre task, and water-filter cleaning every 50 hours for the user. |
Those figures come from the official manuals, not from a Freshway product page, and they only apply to the named models. If your machine’s manual gives a different interval or oil type, follow that document. The milky oil article covers the grey or white oil symptom in more detail. Catch used oil and dispose of it under the site’s waste rules.
Bypass heat, unloaders and chemical use
When the trigger is released, the pump is often still turning. A working unloader or total-stop system sends the water into bypass, or stops the motor, so pressure does not climb without a path. A long bypass run can heat the water in the pump loop. Follow the manual for how long the machine may sit in bypass, and do not leave a running machine unattended.
If the machine pulses, surges or will not build pressure, the unloader is one of the parts to consider, but it is not the only cause. The unloader and bypass pulsing guide is the next diagnostic step. Replacing an unloader is a parts job for a competent technician with the machine isolated; it is not a pre-start check.
Official Kranzle manuals for the K1152TST, K2160TST and HD7/122TS say the cleaner is to be used for high-pressure water jet cleaning without detergents, or for low-pressure cleaning work with detergents, for example with a foam injector or washing brush. Do not run a chemical through the high-pressure pump unless the manual for that model clearly allows it. Flush as instructed after any allowed chemical use.
Shutdown, frost and records
At the end of the shift, release pressure with the gun, isolate the power or engine, and disconnect the water as the manual describes. Official Kranzle manuals say to keep the machine in a frost-free room in winter and to empty it completely for frost protection. In much of Australia frost is occasional, but a machine left full in a cold plant room can still be damaged. Follow the shutdown and storage pages in the manual rather than inventing an antifreeze method.
Electric machines should be connected through a protected outlet. SafeWork NSW provides guidance on residual current devices and on electrical inspection and testing. Keep a simple record of hours, oil changes, filter cleans and repairs. Official Kranzle manuals also call for a periodic inspection by a qualified person; use the interval in the document that belongs to your machine.
Distributor-hosted manuals for several Kranzle and Hotwash models are collected on the Powerblast operations manuals page, including the official K1152TST operating manual and the official HW1310 operating manual cited above. Always match the PDF to the exact model and revision in hand.
When the checklist is not enough
Stop and isolate the machine if you see oil in the water, water in the oil, a burst hose, a seized trigger, a missing guard, or a pump housing that is too hot to approach safely. Freshway’s service and repairs page lists pressure washers among the equipment it repairs, and names Karcher, Pacvac, Nilfisk, Numatic, Kerrick, Makita and DeWalt. That page does not list Kranzle as a serviced brand, so this checklist does not claim a Freshway workshop repair for Kranzle machines. Use the manufacturer’s service path and the official manual for those models. Freshway does list some Kranzle-fit parts, such as the inlet filter above, on the current product pages.
A practical daily order
Isolate, inspect, confirm oil and inlet water, then start with the supply open and the pump primed. Watch for leaks, noise and unstable pressure during the first minutes. Shut down as the manual describes, and record what you found. That sequence is slower than skipping the strainer, and much cheaper than a ruined pump.
Click & collect from our warehouse at 208 Princes Highway, Arncliffe NSW 2205 is available by prior arrangement only. We will notify you when the order is ready for collection, or contact us on 1300 567 002 for a delivered quote to your site.
Frequently asked questions
How often should you change pressure washer pump oil?
Only as the official manual for that model requires. Kranzle manuals for several electric models call for a first change after about 50 hours, then yearly or after 250 hours. The HW1310 manual calls for a first change after 50 hours, then every 500 hours or once a year. Do not copy one interval onto another brand.
What does grey, white or milky pump oil mean?
It often means water has mixed with the oil. Official Kranzle manuals say to change the oil if it turns grey or white. The HW1310 manual says to call the technical service centre immediately if the oil has a milky appearance. Stop using the machine until that check is done.
Can detergent be put through the high-pressure pump?
Only if the official manual for that model allows it. Several Kranzle manuals limit detergent use to low-pressure work with a foam injector or washing brush, and say high-pressure jetting should be without detergents. Flush as the manual instructs after any allowed chemical use.
How long can a pump run in bypass with the trigger released?
Only as long as the model manual allows. Bypass can heat the water in the pump loop. A working unloader or total-stop system protects the pump, but it is not a reason to leave the machine running unattended.
