Kress KR233E.1 RTKⁿ 12,000 m² Robotic Lawn Mower with OAS – Commercial-Grade Precision for the Largest Landscapes
The Kress KR233E.1 RTKⁿ Robotic Lawn Mower is engineered for expansive commercial grounds, estates, sports fields, parks and large private properties requiring professional-grade precision and efficiency.
Using advanced RTKⁿ satellite-guided technology, it delivers true centimeter-level accuracy without the need for any on-site antennas, beacons or boundary wires.
Designed to maintain up to 12,000 m² (recommended) and capable of handling an impressive 18,000 m² (maximum), the KR233E.1 combines dual-disc mowing, dual-layer razor blades, systematic parallel-line navigation and an intelligent MAP™ mowing engine to deliver flawless striped finishes over massive turf areas. With TeamWork™ collaborative technology, multiple KR233E.1 robots can operate on the same site simultaneously — increasing productivity and eliminating overlap.
Featuring an advanced Obstacle Avoidance System (OAS), in-hub drive motors, energy-recycling RBS™ braking, OTA updates and anti-theft tracking, this mower provides a fully autonomous, future-proof solution for world-class turf management.
Key Features
Centimeter-Level Accuracy – No On-Property Antenna Required
RTKⁿ satellite correction enables unmatched accuracy without installing base stations or boundary wires.
Satellite-Guided, Wire-Free Installation
No perimeter wire needed. Simply map zones in the Kress app and begin mowing.
Massive 12,000–18,000 m² Coverage Capacity
Recommended for 12,000 m², capable of maintaining up to 18,000 m² every 72 hours.
Large 35 cm Cutting Width
Dual-disc configuration increases mowing efficiency for large estates and commercial properties.
Dual-Layer Razor-Sharp Blades
Engineered to cut dense, thick and overgrown grass with precision across two cutting planes.
Integrated Obstacle Avoidance System (OAS)
Automatically detects, slows and maneuvers around obstacles for uninterrupted mowing.
Multi-Zone Precision Navigation
Moves between separate turf zones and complex areas with accurate satellite guidance.
Dead Reckoning & Inertial Navigation
Maintains accurate paths under shade, near buildings or when satellite signals weaken.
Systematic Parallel-Line Mowing
Creates perfectly aligned stripes and maximises coverage efficiency.
MAP™ Mowing Action Plan
Adapts mowing paths based on real-time conditions, turf density and ground layout.
TeamWork™ Multi-Mower Collaboration
Multiple mowers operate in the same area without overlap or collision.
Auto-Leveling Cutting Disc
Floating blade system adapts to uneven ground for consistent cutting height.
Electronic Cutting Height Adjustment
Change cutting height (30–60 mm) via the app for precise turf management.
In-Hub Direct Drive Motors
Gearless, maintenance-friendly drive motors deliver smooth, powerful traction.
RBS™ Regenerative Brake System
Recycles downhill energy back into the battery for improved runtime.
IPX5 Wash-Down Ready
Chassis can be safely cleaned with a garden hose.
Anti-Theft Protection
Real-time geo-tracking, PIN lock, auto-lock and app monitoring.
Technical Specifications
- Maximum Area: 18,000 m²
- Recommended Area: 12,000 m²
- Navigation: RTKⁿ satellite-guided
- Obstacle Avoidance: OAS
- Cutting Width: 35 cm
- Cutting Height: 30–60 mm (electronic)
- Blades: 12 (dual-layer blade system)
- Navigation Pattern: Systematic parallel lines
- Maximum Slope: 40%
- Sound Level: 62 dB
- Battery Capacity: 10 Ah (KA3010)
- Battery Voltage: 20 V
- Battery Type: Li-Ion
- Drive System: In-hub gearless motors
- Weather Protection: IPX5
- Front Wheels: 2
- Connectivity: 4G, App, OTA updates
- Size: 762 × 555 × 296 mm
- Weight: 20 kg
- Cutting Methods: Logic pattern
- Sensors: Lift sensor, electric fence, anti-theft lock, low inertia blades
- Charging: Side charge
- TeamWork™: Yes
- Display: LCD
In the Box
- 1 × Kress Mission Mega RTKn 12000 KR233E.1 Robotic Mower
- 1 × Battery Pack (KA3010)
- 1 × Charger (KA3717 / KA3817)
- 1 × Charging Base
- 1 × Charging Tower
- 1 × RTK Antenna
- 1 × Magnetic Strip
- 36 × Spare Blades
- 36 × Blade Fixing Screws
- 8 × Charging Base Fixing Nails
- 1 × Hex Key
- 1 × Hexagon Screwdriver
- 1 × Wrench for RTK Antenna
- 2 × Measurement Gauges
- 1 × Screws Set
- Pegs
- Manuals & Documentation
Why Choose the Kress KR233E.1?
Built for the Biggest Lawns
Ideal for business parks, expansive estates, sports grounds, lifestyle farms, and large residential properties.
Perfect, Professional Stripes Every Day
Systematic mowing ensures visually stunning, uniform stripe patterns across massive areas.
Handles the Most Complex Landscapes
Satellite guidance + OAS + multi-zone routing = seamless navigation in demanding layouts.
Collaborative Multi-Mower Operation
TeamWork™ lets multiple units cover huge spaces efficiently without overlap.
Superior Cutting Power
Dual-disc + double-layer blades easily handle tall, dense or overgrown grass.
Future-Proof Smart Technology
OTA updates continuously enhance navigation, safety and mowing intelligence.
Low Maintenance, High Productivity
Direct-drive motors, IPX5 wash-down design and long-lasting batteries reduce service downtime.
Unmatched Precision
Centimeter-level accuracy ensures every blade of grass is cut exactly where it should be.
