Kress KR174E.1 – RTKⁿ 5,000 m² Robotic Lawn Mower with OAS
The Kress KR174E.1 RTKⁿ robotic lawn mower delivers professional-grade precision for large residential and commercial properties.
Engineered with satellite-guided navigation, dual-layer razor blades, and real-time obstacle avoidance, this mower achieves centimeter-level accuracy without boundary wires, antennas, or complex setup. Designed to handle dense grass, large turf zones, slopes, and challenging terrain, the KR174E.1 is built to maintain up to 5,000 m² (recommended) with a polished, perfectly striped finish.
With systematic parallel-line mowing, intelligent MAP™ route planning, electronic height control, dead-reckoning capability under shade, and fully connected 4G/OTA support, the KR174E.1 redefines autonomous turf care for demanding environments.
Key Features
RTKⁿ Precision – No Perimeter Wire Required
Achieves satellite-guided, centimeter-level accuracy with no need for physical boundary installation or stationary antennas.
Dual-Layer Razor Blades
Two cutting planes slice through dense, tall and overgrown grass with professional clean-cut performance.
Obstacle Avoidance System (OAS)
Intelligent sensing actively avoids obstacles and maintains smooth mowing trajectories.
Multi-Zone Capability
Navigates complex properties and multiple turf areas with guided routing.
Dead-Reckoning Under Shade
Maintains accurate navigation when satellite signals are partially obstructed by buildings or trees.
Systematic Parallel-Line Mowing
Creates crisp, consistent stripes across large lawns for a professional appearance.
Auto-Leveling Cutting Disc
Floating deck adapts to uneven surfaces and protects grass from scalping.
MAP™ Mowing Action Plan
Calculates and adjusts mowing paths dynamically for maximum efficiency.
Electronic Height Control
Adjust height (30–60 mm) via the Kress app with precise digital control.
RBS™ Regenerative Brake System
Converts downhill motion into energy to extend runtime.
IPX5 Washable Design
Fully hose-down washable while remaining protected against water jets.
Complete App Control & Anti-Theft Protection
Live tracking, PIN lock, electric fence, and auto-lock security features included.
Technical Specifications
- Recommended Area: 5,000 m²
- Maximum Area: 7,000 m²
- Navigation: RTKⁿ satellite-guided
- Obstacle Avoidance: OAS
- Cutting Width: 22 cm
- Cutting Height: 30–60 mm (electronic)
- Blades: 6 (dual-layer)
- Self-Levelling Blade Disc: Yes
- Navigation Pattern: Systematic
- Maximum Slope: 40%
- Sound Level: 61 dB
- Weather Resistance: IPX5
- Battery Capacity: 6 Ah
- Battery Voltage: 20 V
- Charging System: Side charge
- Sensors: PIN, lift sensor, electric fence, theft protection, auto lock
- Connectivity: 4G, App, OTA updates, USB
- Size: 647 × 470 × 290 mm
- Weight: 12.6 kg
- Front Wheels: 2
- Display: LCD
In the Box
- 1 × Kress Mission RTKn 5000 KR174E.1
- 1 × Battery (KA3010)
- 1 × Charger (KA3717 / KA3817)
- 1 × Charging Base
- 1 × Charging Tower
- 1 × RTK Antenna
- 1 × Magnetic Strip
- 9 × Blades
- 9 × Blade Screws
- 6 × Charging Base Nails
- 1 × Hex Key
- 1 × Hexagon Screwdriver
- 1 × Wrench for RTK Antenna
- 2 × Measurement Gauges
- Pegs
- Manuals & Documentation
Professional-Grade Benefits
Designed for Large-Scale Lawns
Ideal for estates, sports grounds, commercial landscapes, and large residential properties up to 5,000 m².
Superior Cutting Performance on Dense Grass
Dual-layer blades deliver clean, powerful cuts — perfect for thick, fast-growing or overgrown lawns.
No-Wire Installation = Zero Ground Work
No digging, no cabling, no future wire repairs required.
Handles Complex Landscapes Effortlessly
Superior pathfinding through multiple zones, curves, edges, and obstacle-heavy terrains.
Daily Perfect Stripes
Parallel-line mowing ensures a polished, premium finish every day.
Smart, Connected, Always Updated
OTA software updates continuously improve navigation, performance, and features.
Built for Harsh Conditions
Waterproof IPX5 body, reinforced internals and robust materials suited for Australian climate demands.
